Standby MCS-T10 Midi Handset UNI-MID-XXX (9)

The MCS-T10 Midi Handset consists of 9 buttons (8 small and one double) with the appropriate legend and key colour.

Each button can be independently configured in terms of operation, legend designation and even back light colour, therefore it is the ideal interface for controlling a variety of vehicle based hazard warning systems when using the MCS range of control systems.

Additionally any button can be programmed for use as PTT (Push To Talk) when activating the built-in microphone.

The unit can be mounted in a variety of ways for both overt and covert applications. This flexibility is achieved as the reverse of the handset has M4 threaded inserts for the addition of a microphone type clip and bracket or to facilitate permanent mounting. A flexible, removable, non-slip, protective rubber surround encases the unit resulting in a robust, hard wearing, professional switch solution.

Can be dash mounted via M4 inserts on reverse or inset into dash via custom made aperture

3 stage back illumination – low brightness when OFF, high brightness when ON and both levels dimmed at night

Button colours are defined by the LED back light, therefore they have no colour when the handset is ‘Off’

All configurations compatible with MCS-32, MCS-16, MCS-8, MCS Mini, Midi and Maxi Systems

If you don’t see what you need please contact our dedicated sales team who will be happy to help.

Please note: The intended use for these handsets are to used in conjunction with Standby MCS control units and will not function as a stand-alone switching unit.

Please note: These handsets are not supplied with switch legends, extension cable, extension cable adapter or rear attachment clip, however they can be purchased separately.

Part Number: UNI-MID-XXX (9)
